XT 7 Telescopic Bumper Pull Series Trailer

XT7 Telescopic Dump Trailer: Unleash the Power

Experience the raw strength and versatility of our XT7 Telescopic Series, crafted to handle the toughest jobs with ease. The XT7 Telescopic Dump Trailer is engineered for maximum lift efficiency, designed to adapt to your most demanding tasks.

Whether you’re hauling landscaping materials or heavy construction loads, the XT7 Telescopic is your go-to choice for contractors, landscapers, and professionals who need a reliable trailer that delivers top-notch performance.

Built with a rugged steel frame and reinforced sidewalls, the XT7 Telescopic Series is designed for durability and long-lasting service. When you need a trailer that can take on anything, the XT7 Telescopic Dump Trailer is here to exceed your expectations, delivering superior performance with every lift.

Fast Facts

Trailer style:
XT 7 Telescopic Bumper Pull Series Spec Sheet

Trailer Specs

Dimensions

  • Length14'
  • Width91"
  • Deck Height27"

Finish

  • TypePowder Coat
  • PreparationSandblasting
  • Default ColourBlack

Weight Ratings

  • GVWR14,000 lbs
  • Empty Weight5,020 lbs
  • Load Capacity15.24yd3 lbs

Warranty

  • Trailer3 year(s)
  • AxleManufacturer 3 year(s)
  • Paint1 year(s)

Tongue

Tongue

  • Type8"x 10lbs. Ultra Stong I Beam frame
  • Tongue Length66.5"

Coupler

  • Coupler2-5/16" adjustable, 6 hole

Jacks

  • Front Jacks12,000 lbs spring loaded adjustable leg crank

Tool Boxes

  • Tool Box Lockable 5.48cu ft toolbox, battery, charger, pump & remote control 5.4 cu ft toolbox, with charger, pump battery and remote control

Safety System

  • Safety Chains5/16" X 35" LG GRD 70
  • Breakaway SystemSafety breakaway system w/cable
  • Reflective TapeDOT-approved safety tape

Dump Bed

Dump Bed

  • Inside Width91"
  • Side Height48" fully formed sides, 10-ga top rail measuring 2.75" x 4.25""
  • Flooring7 ga smooth plate flooring
  • Fenders14 ga with 11 ga reinforcements
  • Stake Pockets17 - 1-5/8" X 3-1/2 X 3"
  • Cross Member3" channel bed with 16" on-center cross-members, 4X4 tube
  • D-Rings4 - 5/8" inside 6 - 1/2" outside

Tilt Frame

  • Type3" X 4.1 lbs channel
  • Cross Member3" channel Bed 16" OC cross member

Cargo

  • Cargo Capacity15.24yd3

Rear Gate

  • GateAdjustable rear spreader gate & barn doors
  • Latching SystemCoreLatch locking system
  • Ramps6' 5" MegaStrength

Lift System

  • PowerDeep cycle battery
  • PumpKIT 12V Hydraulic Pump
  • Controller14' cable
  • LiftHD Telescopic cylinder
  • Tilt Angle45"

Tarp

  • Tarp Kit95" extra wide crank roller (Optional)

Running Gear

Tires

  • SizeST235/80R16LRE (7 K) or ST235/85R16LRE (8)
  • Ply10
  • Rating3,520
  • Rims16" 8-Hole wheels (7 K )
  • Bolt Pattern8X6.5

Suspension

  • Axle TypeTandem axles includes electric brakes
  • Axles7K or 8K
  • BrakesElectric

Electrical & Lighting

Wiring

  • Front Plug7 pin
  • Frame WiringAll weather wiring & harness

Battery & Charging

  • BatteryDeep cycle
  • Charging System5A12v

Lighting

  • Side MarkersDOT-Approved LED
  • Rear LightsDOT-Approved LED

FAQs for Dump Trailers

In the market for a dump trailer? Here are some of the most common questions we hear, along with answers that can help you in making the right purchase.
Have more questions? Contact us anytime.

Q: How do I know what size dump trailer I need?
A: The size of dump trailer you need depends on the type and volume of material you plan to haul. Common sizes for dump trailers range from 5′ x 10′ for smaller jobs to 7′ x 14′ or larger for heavy-duty tasks. Consider the capacity, dimensions, and weight limits that best suit your work.

Q: Should I choose a bumper pull or gooseneck dump trailer?
A: Bumper pull trailers are easier to maneuver and are ideal for lighter loads and tighter spaces. Gooseneck trailers offer better stability and higher weight capacity, making them suitable for heavy-duty applications.

Q: What materials can a dump trailer handle?
A: Dump trailers are designed to handle a wide range of materials, including gravel, dirt, sand, mulch, debris, and construction materials. Ensure your dump trailer has the appropriate capacity and durability for your specific needs.

Q: How do I know if my vehicle can tow a dump trailer?
A: Check your vehicle’s towing capacity in the owner’s manual. Compare it with the dump trailer’s Gross Vehicle Weight Rating (GVWR), which includes the trailer’s weight and load. Your vehicle should be able to safely tow the full GVWR.

Q: What type of hydraulic system is best for a dump trailer?
A: Most dump trailers use either scissor lift or direct push hydraulic systems. Scissor lifts provide more stability and are better for heavier loads, while direct push systems are more straightforward and cost-effective for lighter loads.

Q: How do I maintain my dump trailer?
A: Regular maintenance includes checking the hydraulic system, inspecting the tires, lubricating moving parts, and ensuring all lights and brakes function properly. You should also clean the trailer bed after use to prevent material build-up and corrosion.

Q: What are the benefits of high-side vs. low-side dump trailers?
A: High-side dump trailers offer increased capacity, making them ideal for hauling bulkier materials. Low-side trailers are easier to load and unload, especially with smaller equipment like wheelbarrows or skid steers.

Q: How do I ensure I’m getting a quality dump trailer?
A: Look for dump trailers made with high-quality materials like reinforced steel frames and durable hydraulic systems. Read reviews, ask for recommendations, and buy from reputable manufacturers who stand behind their products with warranties and customer support.
